Introduction to the process principle of particulate compressed air filter

　　As a power source, compressed air has many flexible uses, such as driving motors, painting, controlling machines and driving devices, etc. Just like plastic processing, compressed air is indispensable in countless processing techniques in the chemical industry.
　　Because the particulate compressed air filter uses a special structure of activated carbon to eliminate the smell of compressed air, in order to maintain the service life of the degreasing and deodorizing filter, please be sure to install the second stage and third stage drying before the degreasing and deodorizing filter Filter, or use other dry filter.

　　The process principle of the particulate compressed air filter is as follows:
　　1. Carry compressed air containing harmful substances such as dust, oil, rust and moisture into the first-stage filter device of the compressed air filter.
　　2. When the compressed air passes through the first-stage cylindrical mesh filter element, a coalescence effect occurs. Larger particles will be adsorbed on the filter material and the water will condense into larger water droplets.
　　3. When entering the separation chamber, the speed of the compressed air slows down, causing the particles to gather again and the water mist condenses on a honeycomb water trap again.
　　4. The water carrying impurity particles flows along the bottom to the drainage device, and is discharged through an automatic or electric drainage valve.
　　5. More than 95% of the water droplets, oil and large particles in the compressed air have been filtered out by the first filter element, and the compressed air after the first stage filtration enters the second stage filter element.
　　6. When the compressed air passes through the second-stage fiber filter made of special cotton, thousands of small vortices will be generated. At the same time, the compressed air will be accelerated dozens of times. The center of the vortex is like a tornado, forming a vacuum state. The water droplets that were not filtered in the first stage of filtration are vaporized, converted, and filtered again, and at the same time, particles as small as 5 microns are completely removed by the second stage filter.
　　7. Clean and dry compressed air with no dust, no rust, no oil, no water droplets is achieved through two-stage filtration, which guarantees the normal operation of pneumatic equipment and prolongs the service life of pneumatic equipment.
